MIG SERIES – MIG 250 WP

39,200.00

+ Free Shipping
Model Name  MIG 250 WP
Voltage Range 1PH AC 230V | 2PH / 3PH AC 415V ±10%
Rated Input Power 220V: 7.7 kVA | 415V: 11.8 kVA
Rated Input Current (A) 220V: 45A | 415V: 16A
No-load Voltage 67V
Output Current Range 50 – 250A
Weld Wire Diameter 0.8 / 1.0 mm
Weld Stick Diameter 2 – 3.2 mm
Wire Feed Speed 18 m/min
CO2 Gasflow Capacity 10 – 15 L/min
Rated Duty Cycle 60%
Weight 22 kg
Dimensions (mm) 470 x 260 x 480
Isolation Class F
Protection Class IP21S



MIG SERIES (IGBT) INVERTER DC MIG/MAG/MMA WELDER

Product Description

  • Advanced SMD surface-mount design
  • With good protection of under voltage, over voltage and over current, it makes machine safe and reliable.
  • Exact digital current / voltage reset, it makes machine be easy operated
  • Advanced IGBT (60K) inverter technology, high working frequency, high working efficiency and energy saving
  • Soft starting and slow feeding arc striking, no exploding wire, removing tip ball at arc ending
  • Constant voltage / constant current output characteristic, one machine with MIG/MMA/simple TIG welding
  • 220V / 415V power input automatically changing, non crystalline core, high capacity and low loss (MIG 250WT)
  • With 2T / 4T working mode, convenient operation
  • Inbuilt wire feeder and can also be used for gas-less welding using flux core wire.
  • With tri-proof design, it ensures working stable and reliable when in kinds of adverse circumstances.
  • 1 Year Warranty.
